Home WiFi

EW-7822UNX

11ax Wireless Dual Band Selectable USB Adapter

  • Comply with IEEE 802.11a/b/g/n/ac/ax standards
  • Support 802.11ax 2T2R with OFDMA/MU-MIMO
  • Support WMM wireless QoS feature
  • Support 20MHz, 40MHz, 80Mhz bandwidth
  • Support 64/128-bit WPA2, WPA3 with IEEE 802.1x functions for high level of security
WIFI6
AX1800
USB2.0




AX1800 | Wireless Speed Up

The AX1800 Wi-Fi 6 USB Adapter delivers blazing-fast WiFi speeds and efficient performance anywhere, providing super-fast dual-band wireless connections with speeds up to 1.8 Gbps — perfect for 4K streaming and short download times.


OFDMA (Orthogonal Frequency Division Multiple Access)

OFDMA is a more efficient data transmission mode, which is ideal for low bandwidth applications, resulting in better frequency reuse and increased efficiency. EW-7822UMX allows many low-bandwidth streams to transmit in parallel, reducing latency and jitter. The higher throughput combined with a more efficient network will enable applications to run through Wi-Fi 6 like never before.


MU-MIMO (Multi-User MIMO)

MU-MIMO is a multi-user, multiple-input, multiple-output technology that increases capacity, facilitates higher speeds and handles more WiFi-intensive activities such as streaming and gaming.
Users can enjoy improved Wi-Fi performance when connected to an MU-MIMO enabled network.


Slick Design | For Gaming

Start with what's connected, the EW-7822UMX is a well-equipped Gaming USB Adapter that delivers speedy throughput and comes with lots of features designed to enhance your online gaming experience. The EW-7822UMX with OFDMA and DL/LP MU-MIMO has features such as fast responsiveness and more. It can handle more data, which means users can easily enjoy multiple streaming applications all at once. With large volume traffic, gaming routers also minimize disturbance and eliminates all buffering and data loss.

EW-7822UNX V1.0A
Main Chipset
Realtek RTL8832BU
Bus Type
USB 2.0 Type A
Frequency Band
2.4000~2.4835GHz , 5.150~5.825GHz (subject to local regulations)
Data Rate
11a: 6/9/12/24/36/48/54Mbps; 11b: 1/2/5.5/11Mbps;
11g: 6/9/12/24/36/48/54Mbps
11n (20MHz): MCS0-07, up to 144Mbps
11n (40MHz): MCS0-07, up to 300Mbps
11ax (40MHz): MCS0-11, up to 573Mbps
11ac (80MHz): VHTMCS0-9, up to 867Mbps
11ax (80MHz): VHTMCS0-11, up to 1201Mbps
Output Power
2.4GHz:
  11b(11M): 8±1.5 dBm, 11g(54M): 7±1.5 dBm
  11n(20MHz, MCS8): 6±1.5 dBm, 11n(40MHz, MCS9): 6±1.5 dBm,
  11ax(20/40MHz, MCS11): 6±1.5 dBm
5GHz:
  11a(54M): 5±1.5 dBm, 11n(20/40MHz, MCS11): 4±1.5 dBm,
  11ac(80MHz, MCS9): 4±1.5 dBm, 11ax(80MHz, MCS11): 4±1.5 dBm
Receive Sensitivity
2.4GHz:
  11b(11M): -85±2dBm, 11g(54M): -73±2dBm
  11n(20MHz, MCS8): -67±2dBm, 11n(40MHz, MCS9): -60±2dBm
  11ax(20MHz, MCS11): -60±2dBm, 11ax(40MHz, MCS11): -57±2dBm
5GHz:
  11a(54M): -71±2dBm, 11n(20MHz, MCS11): -59±2dBm, 11n(40MHz, MCS11): -56±2dBm, 11ac(80MHz, MCS9): -57±2dBm, 11ax(80MHz, MCS11): -55±2dBm
Antenna
Internal PiFa Antennas x 2 (2T2R)
Drivers
Windows 10/11, Linux
Dimension
9(H) x 16(W) x 25.5(D) mm
Temperature
Operating: 32~104°F (0~40°C) , Storage: -4~140°F (-20~60°C)
Humidity
Operating: 0~90% (NonCondensing), Storage: Max. 95% (NonCondensing)
*Specifications may be changed without prior notice
