Modular Design

The EW-7489WAX is a family of QCA based Maple indoor/outdoor AP solutions.  By leveraging the common coreboard, it is possible to save the certification cost. In addition, the available M.2 slot allows the AP to upgrade to WiFi-6E when the need comes.


Large Memory Size

The EW-7489WAX features 512MB of NAND Flash and 1GB of DDR3 RAM.  It is twice as large as APs in its class.  This allows more firmware features to be available for development.  It offers utmost flexibility as a software development platform.


USB and Console Port

The AP has an USB port for storage when there is a need to upgrade firmware via USB port. In addition, a MicroUSB console port is included for diagnostic and recovery functions.


Full Feature Enterprise Software

The EW-7489WAX is customized with complete enterprise firmware.  Starting from wireless functions such as OFDMA, target wake time, roaming, auto power, airtime faireness, multiple SSID&VLAN; to authentication based function such as radius server, captive portal, social media. login, client isolation, rogue AP detection.  In addition, diagnostic function such as site survey, packet capture and Syslog are also available.  The full fledged firmware features cover all enterprise applications.
